    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    Ask Lasest Price
    Brand Name : HOTHMI
    Model Number : HTG240120A
    Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram
    Supply Ability : 99999
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    240X120 Graphic COG LCD UC1608 | FSTN Display With Side White Backlight/HTG240120A

    HTG240120A | Monochrome Graphic COG | 240x120 Pixels | Transflective LCD | Side White Backlight | FSTN (+) Positive Display


    HOTLCD 240x120 graphic Chip-On-Glass (COG) Liquid Crystal Display shows dark pixels on a white background. This transflective LCD Display is visible with ambient light or a backlight while offering a wide operating temperature range from -20 to 70 degrees Celsius. This HTG240120A display has an optimal view of 6:00, operates at 3.3V supply voltage and is RoHS compliant.


    Product parameters


    ITEMSTANDARD VALUEUNIT
    Number of dots240x120dots
    Module dimension84.0x50.0x6.0mm
    View display area67.17x33.57mm
    Dot size0.25x0.25mm
    Dot pitch0.28x0.28mm
    Operating temp-25~80
    Storage temp-30~80
    Driving Method1/ 128 DUTY,1/ 12 BIAS,VOP= 3.3V
    Viewing direction12H
    Display modeFSTN
    Display typeTRANSMISSIVE / NEGATIVE
    Driver ICUC1608
    Backlight

    WHITE

    Product applicationindustrial control

    Mechanical Data


    Item

    Standard Value

    Unit

    Module Dimension

    84.0x50.0x6.0

    mm

    Viewing Area

    67.17x33.57

    mm

    Dot Pitch

    0.28x0.28

    mm

    Dot Size

    0.25x0.25

    mm


    Electrical Characteristics


    Item

    Symbol

    Standard value
    typ.

    Unit

    Input Voltage

    VDD

    3.3

    V

    Recommended LCD Driving
    Voltage for Normal Temp.
    Version module @25°C

    Vo-Vss

    15.5

    V


    All Products


    Reliability TestingCustomers can expect all production parts to meet or exceed operational requirements over temperature, humidity, and vibration.
    Glass CleanlinessCustomers can expect glass to be protected by liners and presented mindful of cleanliness standards. This means glass will be clean of contaminants, fingerprints, and other foreign material.
    Bezel AppearanceBezels will be uniformly painted free of foreign materials and distracting cosmetic blemishes. Our standards maintain a clean scratch-free surface.
    PCB AppearancePCB’s are delivered with long-term reliability in mind. Finishes are free of bubbles, foreign contaminants, and meet all UL fire requirements. PCB materials will always be delivered within industry norms. PCB edges will be cleanly cut and void of burrs.
    SolderingSoldering of all leaded and SMT components is consistent in providing the mechanical security and electrical connectivity.
    ConsistencyOur manufacturing and inspection processes ensure product consistency from lot to lot. This means orders processed over the years will continually meet your expectations. We do this by exacting manufacturing specifications, with attention to detail in our processes, and by comparing to the golden units.
    Product IntegrityQuality in product manufacturing ensures integrity in construction. Customers can expect tight assembly without worry of loose parts or missing material. Our products will meet all environmental expectations including temp, humidity, & vibration conditions.

    Search Keyword: lcd 240x120, lcd 240x120, 240x120 lcd, 240 x 120 lcd

    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    LCD Custom Solutions

    Cable Customization

    Adjust the length, position, and pinout of your cables or add additional connectors. Get a cable solution that’s precisely designed to make your connections streamlined and secure.

    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A
    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    Connector Customization

    Easily modify any connectors on your display to meet your application’s requirements. Our engineers are able to perform soldering for pin headers, boxed headers, right angle headers, and any other connectors your display may require.


    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    Interface Customization

    Choose from a wide selection of interface options or talk to our experts to select the best one for your project. We can incorporate HI, USB, SPI, VGA and more into your display to achieve your design goals.


    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    PCB Modifications

    Choose from a wide selection of changes including shape, size, pinout, and component layout of your PCB to make it a perfect fit for your application.


    240X120 LCD Module TFT Graphic With Side White Backlight HTG240120A

    HTG240120A.pdf
